DC24V Acetabula Electromagnet | JIANYUAN

24VDC 10.7W Holding Electromagnet Force 45kg (450N) For JSP-8525K | JIANYUAN

High-precision, with strong suction force and sensitive response, electromagnetic iron catcher

An electromagnetic relay is a commonly used switch control device. Its structure mainly consists of a core, a coil, contacts, springs, etc. It uses the magnetic force of an electromagnet to control mechanical actions and is widely applied in electrical control and automation fields. The normally-closed electromagnetic relay is very useful in applications where the circuit needs to remain closed even after power failure. For example, in safety systems, when the power supply fails, the contacts of the relay close to ensure the normal operation of safety equipment.

The holding force electromagnet wiring installation connection is divided into 4 lines:

blue and yellow lines control signals. When the electromagnet is powered off at 24VDC, it gives a normally-closed signal; when the electromagnet is powered on at 24VDC, it gives a normally-open signal. The lifespan verification is over 1 million times and it continues to work.

Also The scenarios he uses are not limited. The appearance and structure can be customized for electromagnets according to the customer's requirements. We are a professional of electromagnet manufacturer. Welcome to come and negotiate.

Brand Name:

JIANYUAN

Model number:

JSP-8525K

Customization:

Support customization

Place of Origin:

China

Payments:

L/C,D/A,T/T,MoneyGram,OA

Lead Time:

1-100(pieces):15(days),101-1000(pieces):30(days),>1000(pieces):To be negotiated(days)

shipping:

Express · Ocean freight · Land freight · Air freight

View size guide

Inquiry

Write a Review

Max. Power

DC24V

Dinension

φ85*25

Solenoids

Holding Electromagnet

Structure

Acetabula Electromagnet

Application

Automobile protector

Force

>450N

Customized support

Support customization

Insulationprotection

100MΩ，1000VDC(at 20℃)

Max.Power

DC24V

Power

10.7W

Working type

Power-off Eectromagnet

Working life

1,000,000 times +

Duty

100%

Holding force

>450N

Voltage

DC24V

Dimension(L*W*H)

φ85*25mm

After-sales Service Provided

Support

Weight (KG)

0.6kg

Product Introduction

DC24V JSP-8525K electronic control device, with strong suction power and highly sensitive magnetic control function

In automated control systems, relay normally-closed electromagnets are widely used. By controlling the opening and closing of the contacts, it is possible to achieve timed control of the equipment. For example, in industrial production lines, relays can be used to control the start and stop of machines, ensuring the smooth progress of the production process. When the system needs to stop, the coil of the relay is de-energized, the contacts close, and the power supply to the equipment is cut off, thereby achieving safe shutdown.

It's easy to assemble

* The base plate has 4 positioning holes, which facilitate installation in various scenarios.

* Suction cup type wiring method: Leadwire on side

Product Characteristic

A normally-closed electromagnet(Holding electromagnet) is an electromagnetic device that remains closed (sucked in) when not powered, and only releases (opens) when powered on.The main characteristics of his work include the following aspects:

* Electromagnet initial state is closed.

* holding electromagnet released after power-on.

* Electromagnet Low power consumption maintenance feature.

* holding force electromagnet controllable response speed.

* Mechanical lifespan and reliability.

* Structural diversity.

Safety redundancy design

Holding force electromagnet at feature of automatically restoring to the closed state in case of an emergency power outage has made it widely used in safety systems, such as:

* Emergency brake device of elevator

* Fire valve closing mechanism

* Locking mechanism of security access control door

FAQ

Can I get samples from your factory?

Yes, sample is free, but the express charge is yours.

If products have some quality problem, how would you deal with?

We will responsible for all the quality problems.

What’s the delivery time ?

Pattern needs 30-60 days, sample need 30-50 days. The first order need 60 days.

What is the standard of package?

Export standard package or special package according to customer requirement.

Do you accept OEM business?

Yes, we are OEM supplier.

What kind of certificate you have ?

We have ISO9001, ISO14001,ISO45001,IATF 16949,SGS.
